What is Kubernetes?
Kubernetes is a open-sourced platform used to deploy containerized application. If a container crashed, kubernetes can restart or replace it automatically. It is automates deployment, monitoring and scaling.
What are the features of Kubernetes?
These are the features of Kubernetes:
- Self-healing
- Resource optimization
- Scaling and load balancing
- Rollouts and Rollbacks
- Automated scheduling
- Containerized infrastructure
What is Kubernetes pod?
Kubernetes pod is the smallest object. Kubernetes do not run container directly, it run pod.
What is Ingress?
It is used to manage external service within a cluster. Traffic routing rules are defined in Ingress resources.
What is a Cluster?
A Cluster is a collection of nodes which works in a single unit. All of these nodes work together to manage containerized application in a single unit.
How to setup Kubernetes Cluster in Ubuntu?
Step 1:
Setup host name at node
$ sudo hostnamectl set-hostname master-node
Step 2:
update and defined host-to-IP mapping
$ sudo nano /etc/hosts
$ 192.168.43.95 master-node
Step 3:
disable swap and load kernel modules
$ sudo swapoff -a
$ sudo swapoff -$ sudo sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab
$ sudo modprobe overlay
$ sudo modprobe br_netfilter
$ sudo modprobe br_netfilter
create configuration file and IP forwarding
$ echo -e "overlay\nbr_netfilter" | sudo tee /etc/modules-load.d/k8s.conf
$ echo -e "net.bridge.bridge-nf-call-ip6tables = 1\nnet.bridge.bridge-nf-call-iptables = 1\nnet.ipv4.ip_forward = 1" | sudo tee /etc/sysctl.d/kubernetes.conf
$ echo -e "net.bridge.bridge-nf-call-ip6tables = 1\nnet.bridge.bridge-nf-call-iptables = 1\nnet.ipv4.ip_forward = 1" | sudo tee /etc/sysctl.d/kubernetes.conf
$ sudo sysctl --system
Step 4:
install and configure containered
install depndency
$ sudo apt update
$ sudo apt install -y curl gnupg2 software-properties-common apt-transport-https ca-certificates
Add GPG key and repository
$ sudo mkdir -p /etc/apt/keyrings $ curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo tee /etc/apt/keyrings/docker.asc > /dev/null $ echo "deb [signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/ubuntu $(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
$ sudo apt update && sudo apt install -y containerd.io
$ sudo mkdir -p /etc/containerd $ containerd config default | sudo tee /etc/containerd/config.toml >/dev/null 2>&1 $ sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml $ sudo systemctl restart containerd
$ sudo curl -fsSLo /etc/apt/keyrings/kubernetes-apt-keyring.asc https://pkgs.k8s.io/core:/stable:/v1.30/deb/Release.key $ echo "deb [signed-by=/etc/apt/keyrings/kubernetes-apt-keyring.asc] https://pkgs.k8s.io/core:/stable:/v1.30/deb/ /" | sudo tee /etc/apt/sources.list.d/kubernetes.list
Step 5:
install Kubernetes components and initialized kubernetes cluster
$ sudo apt update
$ sudo apt install -y kubelet kubeadm kubectl
How to install minikube at Ubuntu ?
curl -LO https://github.com/kubernetes/minikube/releases/latest/download/minikube-linux-amd64
sudo install minikube-linux-amd64 /usr/local/bin/minikube && rm minikube-linux-amd64
Start your cluster
minikube start
How to install kubectl at Ubuntu ?
Download the latest release
curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
Make kubectl binary executable
chmod +x ./kubectl
Move the binary into your PATH
sudo mv ./kubectl /usr/local/bin/kubectl
install kubectl-convert
sudo install -o root -g root -m 0755 kubectl-convert /usr/local/bin/kubectl-convert
check the version
kubectl version
make the shorthand alias for kubectl = k
alias k=kubectl complete -o default -F __start_kubectl k
How to get basic information and addresses about cluster’s control plane ?
kubectl cluster-info
get more detail information about each component:
kubectl cluster-info dump
get status information about nodes:
k get nodes
get health status of a node
k describe node minikube
How to unscheduled new pod but make existing pod running ?
k cordon minikube
How to reverse previous step?
k uncordon minikube
How to lists all virtual clusters inside my cluster?
k get namespace
How to create namespaces?
k create namespace prod
k create namespace dev
k create namespace test
How to check status of all these namespaces?
kubectl get namespaces
How to delete a namespace?
k delete namespace prod
How to get all information about a “namespace”?
k describe namespace prod
How to find resources from default namespace?
kubectl get pods
How to get resources from “dev” namespace?
k get pods -n dev
How to create node?
kubectl create deployment hello-node --image=k8s.gcr.io/echoserver:1.4
kubectl create deployment hello-node --image=k8s.gcr.io/echoserver:1.4 -n dev
How to get status of all pods in all namespaces?
kubectl get pods --all-namespaces
How to get a list of activity?
kubectl get events -n dev
How to get a list of all events?
kubectl get events --all-namespaces
How to create service and expose a node to the port?
kubectl expose deployment hello-node --type=LoadBalancer --port=8080 -n dev
How to check status of the service?
k get services
How to check kubernetes cluster is working correctly and check to access?
minikube service hello-node -n dev
Minikube commands
Installation: https://minikube.sigs.k8s.io/docs/start/
minikube config set driver docker
minikube start // stop
minikube status
minikube dashboard --url
minikube service <applicaiton-service-name>
Kubectl Insallation/Configuration
Installation: https://kubernetes.io/docs/tasks/tools/install-kubectl-linux/
curl -LO "https://dl.k8s.io/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl.sha256"
sudo install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl
cat ~/.kube/config // kubectl config view
alias k='kubectl'
cat ~/.kube/config // kubectl config view alias k='kubectl'
Kubectl commands
kubectl get namespace
kubectl get deployment
kubectl get replicasetP
kubectl get configmap
kubectl get nodes
kubectl describe nodes
kubectl get events
minikube service mywebapp
Cluster Management
kubectl cluster-info
kubectl get nodes
kubectl describe node minikube
kubectl cordon minikube
kubectl drain minikube --ignore-daemonsets=true --force
kubectl uncordon minikube
Namespaces
kubectl get namespace
kubectl create namespace dev
kubectl create namespace test
kubectl delete namespace test
k create -f namespaces/namespace-prod.yaml
k describe namespace prod
# OPTIONAL kubectl config set-context --current --namespace=<NAMESPACE NAME>
Your Hello World Kubernetes Project
kubectl get get pods
kubectl get pods -n dev
kubectl create deployment hello-node --image=k8s.gcr.io/echoserver:1.4
kubectl create deployment hello-node --image=k8s.gcr.io/echoserver:1.4 -n dev
kubectl get deployments --all-namespaces
kubectl get events -n dev
kubectl expose deployment hello-node --type=LoadBalancer --port=8080
kubectl get services
minikube service hello-node
//On cloud providers that support load balancers, an external IP address would be provisioned to access the Service. On minikube, the LoadBalancer type makes the Service accessible through the minikube service command.
Deployment
kubectl apply -f solution/v1.yaml
Service LoadBalancers
kubectl apply -f solution/v2.yaml
Config Maps and Scaling
kubectl apply -f solution/v3.yaml
Resource Limits
kubectl apply -f solution/v4.yaml
Troubleshooting, Logs, Rollouts, Draining Nodes
k describe deployment mydeployment
Logs
k logs -f -l app=mywebapp
Rollouts
kubectl rollout k rollout restart deployment mydeployment kubectl drain minikube --ignore-daemonsets=true --force
